FAG F516-B-L

Özellikler

Marka	FAG
Ürün No	F516-B-L FAG
Üretici No	0383830630000
EAN	4012801213189
Kategori	Yatak - Y Tipi

Ağırlık ve Boyutlar

Dış (D) MM	196
En (B) MM	101
Dış (D) Inch	7.7165
En (B) Inch	3.9764
Ağırlık	10 kg

Data from Schaeffler (medias)

Shaft diameter (d 1) mm	70
Flange width (a) mm	196
Height flange (h 1) mm	196
Total width with cover (g 2) mm	110
Number of fastening holes	4
ECLASS number	23-05-17-02
ECLASS2 number	23-05-17-02
Medias description	Flanged housing for various bearing types, with conical bore and clamping sleeve, continuous shaft

Suffix description

B	Open Ends On Both Sides Of The Housing
L	Flake Graphite Cast Iron (Standard)
