FAG F515-B-L

Özellikler

Marka	FAG
Ürün No	F515-B-L FAG
Üretici No	0383830550000
EAN	4012801213172
Kategori	Yatak - Y Tipi

Ağırlık ve Boyutlar

Dış (D) MM	190
En (B) MM	97
Dış (D) Inch	7.4803
En (B) Inch	3.8189
Ağırlık	9.5 kg

Data from Schaeffler (medias)

Shaft diameter (d 1) mm	65
Flange width (a) mm	190
Height flange (h 1) mm	190
Total width with cover (g 2) mm	104
Number of fastening holes	4
ECLASS number	23-05-17-02
ECLASS2 number	23-05-17-02
Medias description	Flanged housing for various bearing types, with conical bore and clamping sleeve, continuous shaft

Suffix description

B	Open Ends On Both Sides Of The Housing
L	Flake Graphite Cast Iron (Standard)
