FAG F511-WB-L

Özellikler

Marka	FAG
Ürün No	F511-WB-L FAG
Üretici No	0383829970000
EAN	4012801213097
Kategori	Yatak - Y Tipi

Ağırlık ve Boyutlar

Dış (D) MM	190
En (B) MM	71
Dış (D) Inch	7.4803
En (B) Inch	2.7953
Ağırlık	4.2 kg

Data from Schaeffler (medias)

Shaft diameter (d 1) mm	50
Flange width (a) mm	190
Height flange (h 1) mm	170
Total width with cover (g 2) mm	82
Number of fastening holes	3
ECLASS number	23-05-17-02
ECLASS2 number	23-05-17-02
Medias description	Flanged housing for various bearing types, wide version with conical bore and clamping sleeve, continuous shaft

Suffix description

W	Plummer Block Housings, Non-Split For Wide Bearings
B	Open On Both Sides
L	Flake Graphite Cast Iron (Standard)
