FAG F510-WB-L

Özellikler

Marka	FAG
Ürün No	F510-WB-L FAG
Üretici No	0383829700000
EAN	4012801213073
Kategori	Yatak - Y Tipi

Ağırlık ve Boyutlar

Dış (D) MM	180
En (B) MM	65
Ağırlık	3.3 kg

Data from Schaeffler (medias)

Shaft diameter (d 1) mm	45
Flange width (a) mm	180
Height flange (h 1) mm	160
Total width with cover (g 2) mm	76
Number of fastening holes	3
ECLASS number	23-05-17-02
ECLASS2 number	23-05-17-02
Medias description	Flanged housing for various bearing types, wide version with conical bore and clamping sleeve, continuous shaft

Suffix description

W	Plummer Block Housings, Non-Split For Wide Bearings
B	Open On Both Sides
L	Flake Graphite Cast Iron (Standard)
