FAG F509-B-L
Fiyatı: 2,215.20 ₺
Özellikler
| Marka | FAG |
| Ürün No | F509-B-L FAG |
| Üretici No | 0167287000000 |
| EAN | 4012801480352 |
| Kategori | Yatak - Y Tipi |
| Dış (D) MM | 180 |
| En (B) MM | 65 |
| Dış (D) Inch | 7.0866 |
| En (B) Inch | 2.5591 |
| Ağırlık | 3.6 kg |
| Shaft diameter (d 1) mm | 40 |
| Flange width (a) mm | 180 |
| Height flange (h 1) mm | 160 |
| Total width with cover (g 2) mm | 70 |
| Number of fastening holes | 3 |
| ECLASS number | 23-05-17-02 |
| ECLASS2 number | 23-05-17-02 |
| Medias description | Flanged housing for various bearing types, with conical bore and clamping sleeve, continuous shaft |
| B | Open Ends On Both Sides Of The Housing |
| L | Flake Graphite Cast Iron (Standard) |
