FAG F507-WA-L

Özellikler

Marka	FAG
Ürün No	F507-WA-L FAG
Üretici No	0384386660000
EAN	4012801480307
Kategori	Yatak - Y Tipi

Ağırlık ve Boyutlar

Dış (D) MM	145
En (B) MM	57
Ağırlık	2 kg

Data from Schaeffler (medias)

Shaft diameter (d 1) mm	30
Flange width (a) mm	145
Height flange (h 1) mm	130
Total width with cover (g 2) mm	63
Number of fastening holes	3
ECLASS number	23-05-17-02
ECLASS2 number	23-05-17-02
Medias description	Flanged housing for various bearing types, wide version with conical bore and clamping sleeve, closed on one side

Suffix description

W	Plummer Block Housings, Non-Split For Wide Bearings
A	One Side Closed
L	Flake Graphite Cast Iron (Standard)
