FAG F505-B-L

Özellikler

Marka	FAG
Ürün No	F505-B-L FAG
Üretici No	0383829030000
EAN	4012801212984
Kategori	Yatak - Y Tipi

Ağırlık ve Boyutlar

Dış (D) MM	110
En (B) MM	50
Dış (D) Inch	4.3307
En (B) Inch	1.9685
Ağırlık	1.2 kg

Data from Schaeffler (medias)

Shaft diameter (d 1) mm	20
Flange width (a) mm	110
Height flange (h 1) mm	100
Total width with cover (g 2) mm	55
Number of fastening holes	3
ECLASS number	23-05-17-02
ECLASS2 number	23-05-17-02
Medias description	Flanged housing for various bearing types, with conical bore and clamping sleeve, continuous shaft

Suffix description

B	Open Ends On Both Sides Of The Housing
L	Flake Graphite Cast Iron (Standard)
