FAG BAX70-F-T-P4S-DBL
Fiyatı: 17,067.00 ₺
Özellikler
| Marka | FAG |
| Ürün No | BAX70-F-T-P4S-DBL FAG |
| Üretici No | 0707250980000 |
| EAN | 4054369888393 |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 70 |
| Dış (D) MM | 110 |
| En (B) MM | 36 |
| İç (d) Inch | 2.7559 |
| Dış (D) Inch | 4.3307 |
| En (B) Inch | 1.4173 |
| Ağırlık | 1.118 kg |
| Fok | Kapaksız |
| Kasa Tipi | TB - Sert Fiber Kafes |
| Kesinlik | P4S Hassasiyet (P4ten Yüksek) |
| Contact Angle | 30 degrees |
| Pairing | DB - O-arrangement, 2 |
| Axial Internal Clearance / Preload | GA - Light Preload |
| Yağlama | Standart Yağlama |
| Width (2B) mm | 36 |
| Axial Static Load Rating C0a (N) | 64000 |
| Axial Dynamic Load Rating Ca (N) | 30000 |
| Limiting speed for grease lubrication (n G Grease) | 9000 |
| Limiting speed for oil lubrication (n G Oil) | 13000 |
| ECLASS number | 23-05-10-02 |
| ECLASS2 number | 23-05-10-02 |
| Medias description | Angular contact ball bearing BAX..-F-T-P4S-DBL |
| F | 30° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DBL | Set Of 2 Bearings O-Arrangement, Light Preload |
