FAG BAX100-F-T-P4S-DBL

Özellikler

Marka	FAG
Ürün No	BAX100-F-T-P4S-DBL FAG
Üretici No	0716742500000
EAN	4047643339087
Kategori	Tek Sıra - Açısal Temaslı

Ağırlık ve Boyutlar

İç (d) MM	100
Dış (D) MM	150
En (B) MM	45
İç (d) Inch	3.937
Dış (D) Inch	5.9055
En (B) Inch	1.7717
Ağırlık	2.52 kg

Ürün Özellikleri

Fok	Kapaksız
Kasa Tipi	TB - Sert Fiber Kafes
Kesinlik	P4S Hassasiyet (P4ten Yüksek)
Contact Angle	30 degrees
Pairing	DB - O-arrangement, 2
Axial Internal Clearance / Preload	GA - Light Preload
Yağlama	Standart Yağlama

Data from Schaeffler (medias)

Width (2B) mm	45
Axial Static Load Rating C0a (N)	118000
Axial Dynamic Load Rating Ca (N)	52000
Limiting speed for grease lubrication (n G Grease)	6300
Limiting speed for oil lubrication (n G Oil)	9000
ECLASS number	23-05-10-02
ECLASS2 number	23-05-10-02
Medias description	Angular contact ball bearing BAX..-F-T-P4S-DBL

Suffix description

F	30° Contact Angle
T	Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S	Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
DBL	Set Of 2 Bearings O-Arrangement, Light Preload
