FAG B7220-C-T-P4S-DUL
Fiyatı: 33,955.80 ₺
Özellikler
| Marka | FAG |
| Ürün No | B7220-C-T-P4S-DUL FAG |
| Üretici No | 0380475000000 |
| Alternatif Kodu |
7220CD/P4ADGA |
| EAN | 4012801618199 |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 100 |
| Dış (D) MM | 180 |
| En (B) MM | 68 |
| İç (d) Inch | 3.937 |
| Dış (D) Inch | 7.0866 |
| En (B) Inch | 2.6772 |
| Ağırlık | 6.42 kg |
| Fok | Kapaksız |
| Kasa Tipi | TB - Sert Fiber Kafes |
| Kesinlik | P4S Hassasiyet (P4ten Yüksek) |
| Contact Angle | 15 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | DL - 2 Univ Bearings Light Preload |
| Yağlama | Standart Yağlama |
| Genişlik (b) mm | 34 |
| Temel statik yük derecesi, radyal (C 0r) | 88000 |
| Limiting speed for grease lubrication (n G Grease) | 7500 |
| Limiting speed for oil lubrication (n G Oil) | 12000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| C | 15° Or 17° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DUL | Set Of 2 Universal Bearings, Light Preload |
