FAG B7213-E-T-P4S-DFM
Fiyatı: 14,586.00 ₺
Özellikler
| Marka | FAG |
| Ürün No | B7213-E-T-P4S-DFM FAG |
| Üretici No | 0385452330000 |
| Alternatif Kodu |
7213ACD/P4ADFB |
| EAN | 4026677415875 |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 65 |
| Dış (D) MM | 120 |
| En (B) MM | 46 |
| İç (d) Inch | 2.5591 |
| Dış (D) Inch | 4.7244 |
| En (B) Inch | 1.811 |
| Ağırlık | 2.02 kg |
| Fok | Kapaksız |
| Kasa Tipi | TB - Sert Fiber Kafes |
| Kesinlik | P4S Hassasiyet (P4ten Yüksek) |
| Contact Angle | 25 degrees |
| Pairing | DF - X-arrangement, 2 |
| Axial Internal Clearance / Preload | UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements |
| Yağlama | Standart Yağlama |
| Genişlik (b) mm | 23 |
| Temel statik yük derecesi, radyal (C 0r) | 36500 |
| Limiting speed for grease lubrication (n G Grease) | 11000 |
| Limiting speed for oil lubrication (n G Oil) | 18000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| E | 25° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DF | Two Single Row Angular Contact Ball Bearings Matched For Mounting In A Face-To-Face Arrangement |
| M | Bearing Matching With Medium Preload |
