FAG B71924-C-T-P4S-UM

FAG B71924-C-T-P4S-UM
FAG B71924-C-T-P4S-UM rulman resim 1
FAG B71924-C-T-P4S-UM rulman resim 2
FAG B71924-C-T-P4S-UM rulman resim 3
Fiyatı: 18,397.80 ₺
Özellikler
Marka FAG
Ürün No B71924-C-T-P4S-UM FAG
Üretici No 0191550770000
Alternatif Kodu 71924CDGB/P4A
EAN 4012801617987
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
En (B) MM 22
En (B) Inch 0.8661
Ağırlık 1.16 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Medias description Spindle bearings B719..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM Single Bearing, Universal, Medium Preload
