FAG B71924-C-T-P4S-K5-UL

Özellikler

Marka	FAG
Ürün No	B71924-C-T-P4S-K5-UL FAG
Üretici No	0191550500000
EAN	4012801458122
Kategori	Tek Sıra - Açısal Temaslı

Ağırlık ve Boyutlar

Dış (D) MM	165
En (B) MM	22
En (B) Inch	0.8661
Ağırlık	1.16 kg

Ürün Özellikleri

Fok	Kapaksız
Kasa Tipi	TB - Sert Fiber Kafes
Kesinlik	K5 - P4S + K5
Contact Angle	15 degrees
Pairing	G - Universal Pairing
Axial Internal Clearance / Preload	UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama	Standart Yağlama

Data from Schaeffler (medias)

Medias description

Spindle bearings B719..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances

Suffix description

C	15° Or 17° Contact Angle
T	Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S-K5	Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter)
UL	Single Bearing, Universal, Light Preload
