FAG B71914-E-T-P4S-K5-UL
Fiyatı: 7,774.40 ₺
Özellikler
| Marka | FAG |
| Ürün No | B71914-E-T-P4S-K5-UL FAG |
| Üretici No | 0191543300000 |
| EAN | 4012801456616 |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 70 |
| Dış (D) MM | 100 |
| En (B) MM | 16 |
| İç (d) Inch | 2.7559 |
| Dış (D) Inch | 3.937 |
| En (B) Inch | 0.6299 |
| Ağırlık | 0.33 kg |
| Fok | Kapaksız |
| Kasa Tipi | TB - Sert Fiber Kafes |
| Kesinlik | K5 - P4S + K5 |
| Contact Angle | 25 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Yağlama | Standart Yağlama |
| Genişlik (b) mm | 16 |
| Radial Static Load Rating C0r (N) | 21800 |
| Radial Dynamic Load Rating Cr (N) | 32500 |
| Temel statik yük derecesi, radyal (C 0r) | "21800.0000" |
| Limiting speed for grease lubrication (n G Grease) | 12000 |
| Limiting speed for oil lubrication (n G Oil) | 19000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Spindle bearing B719..-E-T-P4S, with steel balls |
| E | 25° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S-K5 | Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter) |
| UL | Single Bearing, Universal, Light Preload |
