FAG B71913-E-T-P4S-K5-UM

Özellikler

Marka	FAG
Ürün No	B71913-E-T-P4S-K5-UM FAG
Üretici No	0380860770000
EAN	4012801970686
Kategori	Tek Sıra - Açısal Temaslı

Ağırlık ve Boyutlar

İç (d) MM	65
Dış (D) MM	90
En (B) MM	13
İç (d) Inch	2.5591
Dış (D) Inch	3.5433
En (B) Inch	0.5118
Ağırlık	0.2 kg

Ürün Özellikleri

Fok	Kapaksız
Kasa Tipi	TB - Sert Fiber Kafes
Kesinlik	K5 - P4S + K5
Contact Angle	25 degrees
Pairing	G - Universal Pairing
Axial Internal Clearance / Preload	UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Yağlama	Standart Yağlama

Data from Schaeffler (medias)

Genişlik (b) mm	13
Radial Static Load Rating C0r (N)	16000
Radial Dynamic Load Rating Cr (N)	23700
Temel statik yük derecesi, radyal (C 0r)	"16000.0000"
Limiting speed for grease lubrication (n G Grease)	13000
Limiting speed for oil lubrication (n G Oil)	20000
ECLASS number	23-05-08-03
ECLASS2 number	23-05-08-03
Medias description	Spindle bearing B719..-E-T-P4S, with steel balls

Suffix description

E	25° Contact Angle
T	Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S-K5	Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter)
UM	Single Bearing, Universal, Medium Preload
