FAG B71908-C-2RSD-T-P4S-UM
Fiyatı: 4,655.20 ₺
Özellikler
| Marka | FAG |
| Ürün No | B71908-C-2RSD-T-P4S-UM FAG |
| Üretici No | 0386235360000 |
| EAN | 4026677739063 |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 40 |
| Dış (D) MM | 62 |
| En (B) MM | 12 |
| İç (d) Inch | 1.5748 |
| Dış (D) Inch | 2.4409 |
| En (B) Inch | 0.4724 |
| Ağırlık | 0.11 kg |
| Fok | 2RU - İki Conta / Temassız Tip |
| Kasa Tipi | TB - Sert Fiber Kafes |
| Kesinlik | P4S Hassasiyet (P4ten Yüksek) |
| Contact Angle | 15 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements |
| Yağlama | Standart Yağlama |
| Genişlik (b) mm | 12 |
| Temel statik yük derecesi, radyal (C 0r) | 9900 |
| Limiting speed for grease lubrication (n G Grease) | 24000 |
| C | 15° Or 17° Contact Angle |
| 2RSD | Lip Seals On Both Sides, Non-Contact |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| UM | Single Bearing, Universal, Medium Preload |
