FAG B71906-E-T-P4S-DBM
Fiyatı: 5,681.00 ₺
Özellikler
| Marka | FAG |
| Ürün No | B71906-E-T-P4S-DBM FAG |
| Üretici No | 0191536600000 |
| Alternatif Kodu |
71906ACD/P4ADBB |
| EAN | 4012801984744 |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 30 |
| Dış (D) MM | 47 |
| En (B) MM | 18 |
| İç (d) Inch | 1.1811 |
| Dış (D) Inch | 1.8504 |
| En (B) Inch | 0.7087 |
| Ağırlık | 0.1 kg |
| Fok | Kapaksız |
| Kasa Tipi | TB - Sert Fiber Kafes |
| Kesinlik | P4S Hassasiyet (P4ten Yüksek) |
| Contact Angle | 25 degrees |
| Pairing | DB - O-arrangement, 2 |
| Axial Internal Clearance / Preload | UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements |
| Yağlama | Standart Yağlama |
| Genişlik (b) mm | 9 |
| Temel statik yük derecesi, radyal (C 0r) | 4150 |
| Limiting speed for grease lubrication (n G Grease) | 28000 |
| Limiting speed for oil lubrication (n G Oil) | 43000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| E | 25° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DBL | Set Of 2 Bearings O-Arrangement, Medium Preload |
