FAG B71905-E-T-P4S-DUL

Fiyatı: 5,424.00 ₺
Özellikler
Marka FAG
Ürün No B71905-E-T-P4S-DUL FAG
Üretici No 0384348490000
Alternatif Kodu 71905ACD/P4ADGA
EAN 4012801454414
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 25
Dış (D) MM 42
En (B) MM 18
İç (d) Inch 0.9843
Dış (D) Inch 1.6535
En (B) Inch 0.7087
Ağırlık 0.08 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload DL - 2 Univ Bearings Light Preload
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 9
Radial Static Load Rating C0r (N) 3600
Radial Dynamic Load Rating Cr (N) 7600
Temel statik yük derecesi, radyal (C 0r) "3600.0000"
Limiting speed for grease lubrication (n G Grease) 32000
Limiting speed for oil lubrication (n G Oil) 50000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearing B719..-E-T-P4S, with steel balls
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
DUL Set Of 2 Universal Bearings, Light Preload
