FAG B71900-E-T-P4S-DUM
Fiyatı: 4,375.80 ₺
Özellikler
| Marka | FAG |
| Ürün No | B71900-E-T-P4S-DUM FAG |
| Üretici No | 0385715790000 |
| Alternatif Kodu |
71900ACD/P4ADGB |
| EAN | 4026677488190 |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 10 |
| Dış (D) MM | 22 |
| En (B) MM | 12 |
| İç (d) Inch | 0.3937 |
| Dış (D) Inch | 0.8661 |
| En (B) Inch | 0.4724 |
| Ağırlık | 0.02 kg |
| Fok | Kapaksız |
| Kasa Tipi | TB - Sert Fiber Kafes |
| Kesinlik | P4S Hassasiyet (P4ten Yüksek) |
| Contact Angle | 25 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | DM - 2 Univ Bearings Medium Pre |
| Yağlama | Standart Yağlama |
| Genişlik (b) mm | 6 |
| Radial Static Load Rating C0r (N) | 1020 |
| Radial Dynamic Load Rating Cr (N) | 2900 |
| Temel statik yük derecesi, radyal (C 0r) | "1020.0000" |
| Limiting speed for grease lubrication (n G Grease) | 70000 |
| Limiting speed for oil lubrication (n G Oil) | 110000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Spindle bearing B719..-E-T-P4S, with steel balls |
| E | 25° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DUM | Set Of 2 Universal Bearings, Medium Preload |
