FAG B7026-C-T-P4S-UM

FAG B7026-C-T-P4S-UM
FAG B7026-C-T-P4S-UM rulman resim 1
FAG B7026-C-T-P4S-UM rulman resim 2
FAG B7026-C-T-P4S-UM rulman resim 3
FAG B7026-C-T-P4S-UM rulman resim 4
Fiyatı: 18,481.80 ₺
Özellikler
Marka FAG
Ürün No B7026-C-T-P4S-UM FAG
Üretici No 0191528250000
Alternatif Kodu 7026CDGB/P4A
EAN 4026677435675
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
Dış (D) MM 200
En (B) MM 33
En (B) Inch 1.2992
Ağırlık 3.15 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Medias description Spindle bearings B70..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM Single Bearing, Universal, Medium Preload
