FAG B7022-E-T-P4S-UL

FAG B7022-E-T-P4S-UL
FAG B7022-E-T-P4S-UL rulman resim 1
FAG B7022-E-T-P4S-UL rulman resim 2
FAG B7022-E-T-P4S-UL rulman resim 3
Fiyatı: 12,230.00 ₺
Özellikler
Marka FAG
Ürün No B7022-E-T-P4S-UL FAG
Üretici No 0167275760000
Alternatif Kodu 7022ACDGA/P4A
EAN 4012801210256
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
En (B) MM 28
En (B) Inch 1.1024
Ağırlık 1.94 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Medias description Spindle bearings B70..-E, adjusted, in pairs or sets, contact angle a = 25°, restricted tolerances
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
