FAG B7018-C-T-P4S-K5-UL

FAG B7018-C-T-P4S-K5-UL
FAG B7018-C-T-P4S-K5-UL rulman resim 1
FAG B7018-C-T-P4S-K5-UL rulman resim 2
FAG B7018-C-T-P4S-K5-UL rulman resim 3
Fiyatı: 11,107.60 ₺
Özellikler
Marka FAG
Ürün No B7018-C-T-P4S-K5-UL FAG
Üretici No 0191521160000
EAN 4012801451604
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
Dış (D) MM 140
En (B) MM 24
En (B) Inch 0.9449
Ağırlık 1.14 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik K5 - P4S + K5
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Medias description Spindle bearings B70..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S-K5 Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter)
UL Single Bearing, Universal, Light Preload
