FAG B7016-E-T-P4S-QBCL

Özellikler

Marka	FAG
Ürün No	B7016-E-T-P4S-QBCL FAG
Üretici No	0384342450000
EAN	4012801451352
Kategori	Tek Sıra - Açısal Temaslı

Ağırlık ve Boyutlar

İç (d) MM	80
Dış (D) MM	125
En (B) MM	88
Ağırlık	3.32 kg

Ürün Özellikleri

Fok	Kapaksız
Kasa Tipi	TB - Sert Fiber Kafes
Kesinlik	P4S Hassasiyet (P4ten Yüksek)
Contact Angle	25 degrees
Pairing	QBC - O-arrangement, 4
Axial Internal Clearance / Preload	UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama	Standart Yağlama

Data from Schaeffler (medias)

Genişlik (b) mm	22
Temel statik yük derecesi, radyal (C 0r)	39000
Limiting speed for grease lubrication (n G Grease)	10000
Limiting speed for oil lubrication (n G Oil)	15000
ECLASS number	23-05-08-03
ECLASS2 number	23-05-08-03

Suffix description

E	25° Contact Angle
T	Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S	Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
QBCL	Four Bearings In O Arrangement <<>>
