FAG B7010-C-T-P4S-K5-UM
Fiyatı: 5,391.40 ₺
Özellikler
| Marka | FAG |
| Ürün No | B7010-C-T-P4S-K5-UM FAG |
| Üretici No | 0380924410000 |
| EAN | 4012801978361 |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 50 |
| Dış (D) MM | 80 |
| En (B) MM | 16 |
| İç (d) Inch | 1.9685 |
| Dış (D) Inch | 3.1496 |
| En (B) Inch | 0.6299 |
| Ağırlık | 0.26 kg |
| Fok | Kapaksız |
| Kasa Tipi | TB - Sert Fiber Kafes |
| Kesinlik | K5 - P4S + K5 |
| Contact Angle | 15 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements |
| Yağlama | Standart Yağlama |
| Genişlik (b) mm | 16 |
| Temel statik yük derecesi, radyal (C 0r) | 16100 |
| Limiting speed for grease lubrication (n G Grease) | 18000 |
| Limiting speed for oil lubrication (n G Oil) | 28000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| C | 15° Or 17° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S-K5 | Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter) |
| UM | Single Bearing, Universal, Medium Preload |
