FAG 7315-B-XL-MP-UA80
Fiyatı: 9,448.20 ₺
Özellikler
| Marka | FAG |
| Ürün No | 7315-B-XL-MP-UA80 FAG |
| Alternatif Kodu |
7315-B-MP-UA80 |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 75 |
| Dış (D) MM | 160 |
| En (B) MM | 37 |
| İç (d) Inch | 2.9528 |
| Dış (D) Inch | 6.2992 |
| En (B) Inch | 1.4567 |
| Ağırlık | 3.51 kg |
| Fok | Kapaksız |
| Kasa Tipi | M - Prinç Kafes |
| Kesinlik | Standart Hassasiyet |
| Contact Angle | 40 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | U8 - Small Axial Clearance (80) |
| Yağlama | Standart Yağlama |
| Genişlik (b) mm | 37 |
| Radial Static Load Rating C0r (N) | 107000 |
| Radial Dynamic Load Rating Cr (N) | 140000 |
| Hız sınırlaması (n G) | 7300 |
| Referans Hızı (n u03d1r) | 4500 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearing 73..-B-XL-MP, single row |
| B | 40° Contact Angle |
| XL | X-Life |
| MP | Machined Brass Cage, Window Type, Rolling Element Riding |
| UA | Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance |
| UA80 | Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance, 80u03bcm |
