FAG 7306-B-XL-TVP-P5-UA
Fiyatı: 1,779.00 ₺
Özellikler
| Marka | FAG |
| Ürün No | 7306-B-XL-TVP-P5-UA FAG |
| Üretici No | 0191169690000 |
| Alternatif Kodu |
7306B.TVP.P5 |
| EAN | 4012801166379 |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 30 |
| Dış (D) MM | 72 |
| En (B) MM | 19 |
| İç (d) Inch | 1.1811 |
| Dış (D) Inch | 2.8346 |
| En (B) Inch | 0.748 |
| Ağırlık | 0.349 kg |
| Fok | Kapaksız |
| Kasa Tipi | P - Plastik Kalıplı Kafes |
| Kesinlik | P5 Hassasiyeti (P6dan Yüksek) |
| Contact Angle | 40 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UA - Universal design for fitting in pairs, bearing pair has slight axial internal clearance in O and X arrangements |
| Yağlama | Standart Yağlama |
| Genişlik (b) mm | 19 |
| Radial Static Load Rating C0r (N) | 22100 |
| Radial Dynamic Load Rating Cr (N) | 35500 |
| Temel statik yük derecesi, radyal (C 0r) | "22100.0000" |
| Hız sınırlaması (n G) | 13500 |
| Referans Hızı (n u03d1r) | 8600 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearing 73..-B-XL-TVP, single row |
| B | 40° Contact Angle |
| XL | X-Life |
| TVP | Moulded Polyamide Window-Type Cage, Rolling Element Riding |
| P5 | Dimensional And Running Accuracy To ISO Tolerance Class 5 |
| UA | Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance |
