FAG 7220-B-XL-JP-UA
Fiyatı: 6,586.00 ₺
Özellikler
| Marka | FAG |
| Ürün No | 7220-B-XL-JP-UA FAG |
| Üretici No | 0191159890000 |
| Alternatif Kodu |
7220-B-JP-UA |
| EAN | 4026677515261 |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 100 |
| Dış (D) MM | 180 |
| En (B) MM | 34 |
| İç (d) Inch | 3.937 |
| Dış (D) Inch | 7.0866 |
| En (B) Inch | 1.3386 |
| Ağırlık | 3.41 kg |
| Fok | Kapaksız |
| Kasa Tipi | S - Çelik veya Standart Kafes |
| Kesinlik | Standart Hassasiyet |
| Contact Angle | 40 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UA - Universal design for fitting in pairs, bearing pair has slight axial internal clearance in O and X arrangements |
| Yağlama | Standart Yağlama |
| Genişlik (b) mm | 34 |
| Radial Static Load Rating C0r (N) | 132000 |
| Radial Dynamic Load Rating Cr (N) | 148000 |
| Temel statik yük derecesi, radyal (C 0r) | "132000.0000" |
| Hız sınırlaması (n G) | 4850 |
| Referans Hızı (n u03d1r) | 4200 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40° |
| B | 40° Contact Angle |
| XL | X-Life |
| JP | Pressed Steel Cage, Rolling Element Guided |
| UA | Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance |
