FAG 7209-B-XL-MP-P6-UA
Fiyatı: 2,156.60 ₺
Özellikler
| Marka | FAG |
| Ürün No | 7209-B-XL-MP-P6-UA FAG |
| Alternatif Kodu |
7209-B-MP-P6-UA |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 45 |
| Dış (D) MM | 85 |
| En (B) MM | 19 |
| İç (d) Inch | 1.7717 |
| Dış (D) Inch | 3.3465 |
| En (B) Inch | 0.748 |
| Ağırlık | 0.43 kg |
| Fok | Kapaksız |
| Kasa Tipi | M - Prinç Kafes |
| Kesinlik | P6 Hassasiyeti (Standarttan Yüksek) |
| Contact Angle | 40 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UA - Universal design for fitting in pairs, bearing pair has slight axial internal clearance in O and X arrangements |
| Yağlama | Standart Yağlama |
| Radial Static Load Rating C0r (N) | 27000 |
| Radial Dynamic Load Rating Cr (N) | 40000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40° |
| B | 40° Contact Angle |
| XL | X-Life |
| MP | Machined Brass Cage, Window Type, Rolling Element Riding |
| P6 | Dimensional And Running Accuracy To ISO Tolerance Class 6 (Better Than Normal) |
| UA | Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance |
