FAG 32220-XL-DF-A230-280
Fiyatı: 9,408.80 ₺
Özellikler
| Marka | FAG |
| Ürün No | 32220-XL-DF-A230-280 FAG |
| Üretici No | 0884757354080 |
| Alternatif Kodu |
32220-DF-A230-280 |
| EAN | 4054369349146 |
| Kategori | Konik Makaralı - Tek Sıra (Çift Metrik) |
| İç (d) MM | 100 |
| Dış (D) MM | 180 |
| En (B) MM | 98 |
| İç (d) Inch | 3.937 |
| Dış (D) Inch | 7.0866 |
| En (B) Inch | 3.8583 |
| Ağırlık | 10 kg |
| Tapered Roller Pair Internal Play | 230-280µm |
| Inner ring total width (2B) mm | 92 |
| Radial Static Load Rating C0r (N) | 950000 |
| Radial Dynamic Load Rating Cr (N) | 680000 |
| Temel statik yük derecesi, radyal (C 0r) | "950000.0000" |
| Hız sınırlaması (n G) | 4250 |
| Outer ring total width (2T) mm | 98 |
| Thermal speed rating (n u03d1r) | 2260 |
| ECLASS number | 23-05-09-10 |
| ECLASS2 number | 23-05-09-10 |
| Medias description | Tapered roller bearing set 322..-XL-DF, X-arrangement |
| XL | X-Life |
| DF | Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings |
| A230.280 | Axial Clearance In µm |
