FAG 32218-XL-DF-A220-270
Fiyatı: 7,543.80 ₺
Özellikler
| Marka | FAG |
| Ürün No | 32218-XL-DF-A220-270 FAG |
| Üretici No | 0864265164080 |
| Alternatif Kodu |
32218-DF-A220-270 |
| EAN | 4054364919627 |
| Kategori | Konik Makaralı - Tek Sıra (Çift Metrik) |
| İç (d) MM | 90 |
| Dış (D) MM | 160 |
| En (B) MM | 85 |
| İç (d) Inch | 3.5433 |
| Dış (D) Inch | 6.2992 |
| En (B) Inch | 3.3465 |
| Ağırlık | 7.12 kg |
| Tapered Roller Pair Internal Play | 220-270µm |
| Inner ring total width (2B) mm | 80 |
| Radial Static Load Rating C0r (N) | 720000 |
| Radial Dynamic Load Rating Cr (N) | 530000 |
| Temel statik yük derecesi, radyal (C 0r) | "720000.0000" |
| Hız sınırlaması (n G) | 4800 |
| Outer ring total width (2T) mm | 85 |
| Thermal speed rating (n u03d1r) | 2650 |
| ECLASS number | 23-05-09-10 |
| ECLASS2 number | 23-05-09-10 |
| Medias description | Tapered roller bearing set 322..-XL-DF, X-arrangement |
| XL | X-Life |
| DF | Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings |
| A220-270 | Axial Clearance In µm |
