FAG 32217-XL-DF-A220-270
Fiyatı: 5,581.80 ₺
Özellikler
| Marka | FAG |
| Ürün No | 32217-XL-DF-A220-270 FAG |
| Üretici No | 0923768864081 |
| Alternatif Kodu |
32217-DF-A220-270 |
| EAN | 4054371170394 |
| Kategori | Konik Makaralı - Tek Sıra (Çift Metrik) |
| İç (d) MM | 85 |
| Dış (D) MM | 150 |
| En (B) MM | 77 |
| İç (d) Inch | 3.3465 |
| Dış (D) Inch | 5.9055 |
| En (B) Inch | 3.0315 |
| Ağırlık | 5.45 kg |
| Tapered Roller Pair Internal Play | 220-270µm |
| Inner ring total width (2B) mm | 72 |
| Radial Static Load Rating C0r (N) | 610000 |
| Radial Dynamic Load Rating Cr (N) | 460000 |
| Temel statik yük derecesi, radyal (C 0r) | "610000.0000" |
| Hız sınırlaması (n G) | 5200 |
| Outer ring total width (2T) mm | 77 |
| Thermal speed rating (n u03d1r) | 2850 |
| ECLASS number | 23-05-09-10 |
| ECLASS2 number | 23-05-09-10 |
| Medias description | Tapered roller bearing set 322..-XL-DF, X-arrangement |
| XL | X-Life |
| DF | Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings |
| A220-270 | Axial Clearance In µm |
