FAG 32022-X-XL-DF-A90-130
Fiyatı: 8,266.20 ₺
Özellikler
| Marka | FAG |
| Ürün No | 32022-X-XL-DF-A90-130 FAG |
| Üretici No | 0837046554082 |
| Alternatif Kodu |
32022-X-DF-A90-130 |
| EAN | 4064328627192 |
| Kategori | Konik Makaralı - Tek Sıra (Çift Metrik) |
| İç (d) MM | 110 |
| Dış (D) MM | 170 |
| En (B) MM | 76 |
| İç (d) Inch | 4.3307 |
| Dış (D) Inch | 6.6929 |
| En (B) Inch | 2.9921 |
| Ağırlık | 6.31 kg |
| Tapered Roller Pair Internal Play | 90-130µm |
| Inner ring total width (2B) mm | 76 |
| Radial Static Load Rating C0r (N) | 790000 |
| Radial Dynamic Load Rating Cr (N) | 490000 |
| Temel statik yük derecesi, radyal (C 0r) | "790000.0000" |
| Hız sınırlaması (n G) | 4350 |
| Outer ring total width (2T) mm | 76 |
| Thermal speed rating (n u03d1r) | 2440 |
| ECLASS number | 23-05-09-10 |
| ECLASS2 number | 23-05-09-10 |
| Medias description | Tapered roller bearing set 320..-X-XL-DF, X-arrangement |
| X | External Dimensions Matched To International Standards |
| XL | X-Life |
| DF | Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings |
| A90-130 | Axial Clearance In µm |
