FAG 32014-X-XL-DF-A80-100
Fiyatı: 3,093.00 ₺
Özellikler
| Marka | FAG |
| Ürün No | 32014-X-XL-DF-A80-100 FAG |
| Üretici No | 0848901694080 |
| Alternatif Kodu |
32014-X-DF-A80-100 |
| EAN | 4054369019872 |
| Kategori | Konik Makaralı - Tek Sıra (Çift Metrik) |
| İç (d) MM | 70 |
| Dış (D) MM | 110 |
| En (B) MM | 50 |
| İç (d) Inch | 2.7559 |
| Dış (D) Inch | 4.3307 |
| En (B) Inch | 1.9685 |
| Ağırlık | 1.81 kg |
| Tapered Roller Pair Internal Play | 80-100µm |
| Inner ring total width (2B) mm | 50 |
| Radial Static Load Rating C0r (N) | 315000 |
| Radial Dynamic Load Rating Cr (N) | 210000 |
| Temel statik yük derecesi, radyal (C 0r) | "315000.0000" |
| Hız sınırlaması (n G) | 6900 |
| Outer ring total width (2T) mm | 50 |
| Thermal speed rating (n u03d1r) | 3800 |
| ECLASS number | 23-05-09-10 |
| ECLASS2 number | 23-05-09-10 |
| Medias description | Tapered roller bearing set 320..-X-XL-DF, X-arrangement |
| X | External Dimensions Matched To International Standards |
| XL | X-Life |
| DF | Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings |
| A80-100 | Axial Clearance In µm |
