FAG 31317-XL-DF-A120-160
Fiyatı: 19,301.60 ₺
Özellikler
| Marka | FAG |
| Ürün No | 31317-XL-DF-A120-160 FAG |
| Üretici No | 0927124104080 |
| Alternatif Kodu |
31317-DF-A120-160 |
| EAN | 4054371051679 |
| Kategori | Konik Makaralı - Tek Sıra (Çift Metrik) |
| İç (d) MM | 85 |
| Dış (D) MM | 180 |
| En (B) MM | 89 |
| İç (d) Inch | 3.3465 |
| Dış (D) Inch | 7.0866 |
| En (B) Inch | 3.5039 |
| Ağırlık | 9.76 kg |
| Tapered Roller Pair Internal Play | 120-160µm |
| Inner ring total width (2B) mm | 82 |
| Radial Static Load Rating C0r (N) | 600000 |
| Radial Dynamic Load Rating Cr (N) | 510000 |
| Temel statik yük derecesi, radyal (C 0r) | "600000.0000" |
| Hız sınırlaması (n G) | 4300 |
| Outer ring total width (2T) mm | 89 |
| Thermal speed rating (n u03d1r) | 2750 |
| ECLASS number | 23-05-09-10 |
| ECLASS2 number | 23-05-09-10 |
| Medias description | Tapered roller bearing set 313..-XL-DF, X-arrangement |
| XL | X-Life |
| DF | Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings |
| A120-160 | Axial Clearance In µm |
