FAG 31315-XL-DF-A100-140
Fiyatı: 10,680.00 ₺
Özellikler
| Marka | FAG |
| Ürün No | 31315-XL-DF-A100-140 FAG |
| Üretici No | 0929090354080 |
| Alternatif Kodu |
31315-DF-A100-140 |
| EAN | 4054371608491 |
| Kategori | Konik Makaralı - Tek Sıra (Çift Metrik) |
| İç (d) MM | 75 |
| Dış (D) MM | 160 |
| En (B) MM | 80 |
| İç (d) Inch | 2.9528 |
| Dış (D) Inch | 6.2992 |
| En (B) Inch | 3.1496 |
| Ağırlık | 7.338 kg |
| Tapered Roller Pair Internal Play | 100-140µm |
| Inner ring total width (2B) mm | 74 |
| Radial Static Load Rating C0r (N) | 475000 |
| Radial Dynamic Load Rating Cr (N) | 410000 |
| Hız sınırlaması (n G) | 4850 |
| Outer ring total width (2T) mm | 80 |
| Thermal speed rating (n u03d1r) | 3150 |
| ECLASS number | 23-05-09-10 |
| ECLASS2 number | 23-05-09-10 |
| Medias description | Tapered roller bearing set 313..-XL-DF, X-arrangement |
| XL | X-Life |
| DF | Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings |
| A100-140 | Axial Clearance In µm |
