FAG 31314-XL-DF-A100-140
Fiyatı: 8,036.40 ₺
Özellikler
| Marka | FAG |
| Ürün No | 31314-XL-DF-A100-140 FAG |
| Üretici No | 0877606734080 |
| Alternatif Kodu |
31314-DF-A100-140 |
| EAN | 4054369559743 |
| Kategori | Konik Makaralı - Tek Sıra (Çift Metrik) |
| İç (d) MM | 70 |
| Dış (D) MM | 150 |
| En (B) MM | 76 |
| İç (d) Inch | 2.7559 |
| Dış (D) Inch | 5.9055 |
| En (B) Inch | 2.9921 |
| Ağırlık | 6.11 kg |
| Tapered Roller Pair Internal Play | 100-140µm |
| Inner ring total width (2B) mm | 70 |
| Radial Static Load Rating C0r (N) | 435000 |
| Radial Dynamic Load Rating Cr (N) | 380000 |
| Temel statik yük derecesi, radyal (C 0r) | "435000.0000" |
| Hız sınırlaması (n G) | 5200 |
| Outer ring total width (2T) mm | 76 |
| Thermal speed rating (n u03d1r) | 3400 |
| ECLASS number | 23-05-09-10 |
| ECLASS2 number | 23-05-09-10 |
| Medias description | Tapered roller bearing set 313..-XL-DF, X-arrangement |
| XL | X-Life |
| DF | Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings |
| A100-140 | Axial Clearance In µm |
