FAG 31313-XL-DF-A120-160
Fiyatı: 7,686.00 ₺
Özellikler
| Marka | FAG |
| Ürün No | 31313-XL-DF-A120-160 FAG |
| Üretici No | 0880632084081 |
| Alternatif Kodu |
31313-DF-A120-160 |
| EAN | 4054371048464 |
| Kategori | Konik Makaralı - Tek Sıra (Çift Metrik) |
| İç (d) MM | 65 |
| Dış (D) MM | 140 |
| En (B) MM | 72 |
| İç (d) Inch | 2.5591 |
| Dış (D) Inch | 5.5118 |
| En (B) Inch | 2.8346 |
| Ağırlık | 5.05 kg |
| Tapered Roller Pair Internal Play | 120-160µm |
| Inner ring total width (2B) mm | 66 |
| Radial Static Load Rating C0r (N) | 375000 |
| Radial Dynamic Load Rating Cr (N) | 330000 |
| Temel statik yük derecesi, radyal (C 0r) | "375000.0000" |
| Hız sınırlaması (n G) | 5500 |
| Outer ring total width (2T) mm | 72 |
| Thermal speed rating (n u03d1r) | 3650 |
| ECLASS number | 23-05-09-10 |
| ECLASS2 number | 23-05-09-10 |
| Medias description | Tapered roller bearing set 313..-XL-DF, X-arrangement |
| XL | X-Life |
| DF | Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings |
| A120-160 | Axial Clearance In µm |
