FAG 31309-XL-DF-A60-100
Fiyatı: 3,352.60 ₺
Özellikler
| Marka | FAG |
| Ürün No | 31309-XL-DF-A60-100 FAG |
| Üretici No | 0898412044080 |
| Alternatif Kodu |
31309-DF-A60-100 |
| EAN | 4054369809299 |
| Kategori | Konik Makaralı - Tek Sıra (Çift Metrik) |
| İç (d) MM | 45 |
| Dış (D) MM | 100 |
| En (B) MM | 54,5 |
| İç (d) Inch | 1.7717 |
| Dış (D) Inch | 3.937 |
| En (B) Inch | 2.1457 |
| Ağırlık | 1.99 kg |
| Tapered Roller Pair Internal Play | 60-100µm |
| Inner ring total width (2B) mm | 50 |
| Radial Static Load Rating C0r (N) | 217000 |
| Radial Dynamic Load Rating Cr (N) | 195000 |
| Temel statik yük derecesi, radyal (C 0r) | "217000.0000" |
| Hız sınırlaması (n G) | 7100 |
| Outer ring total width (2T) mm | 54,5 |
| Thermal speed rating (n u03d1r) | 4650 |
| ECLASS number | 23-05-09-10 |
| ECLASS2 number | 23-05-09-10 |
| Medias description | Tapered roller bearing set 313..-XL-DF, X-arrangement |
| XL | X-Life |
| DF | Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings |
| A60-100 | Axial Clearance In µm |
