FAG 31308-XL-DF-A50-90
Fiyatı: 2,644.00 ₺
Özellikler
| Marka | FAG |
| Ürün No | 31308-XL-DF-A50-90 FAG |
| Üretici No | 0847938304081 |
| Alternatif Kodu |
31308-DF-A50-90 |
| EAN | 4054364798598 |
| Kategori | Konik Makaralı - Tek Sıra (Çift Metrik) |
| İç (d) MM | 40 |
| Dış (D) MM | 90 |
| En (B) MM | 50,5 |
| İç (d) Inch | 1.5748 |
| Dış (D) Inch | 3.5433 |
| En (B) Inch | 1.9882 |
| Ağırlık | 1.52 kg |
| Tapered Roller Pair Internal Play | 50-90µm |
| Inner ring total width (2B) mm | 46 |
| Radial Static Load Rating C0r (N) | 165000 |
| Radial Dynamic Load Rating Cr (N) | 153000 |
| Temel statik yük derecesi, radyal (C 0r) | "165000.0000" |
| Hız sınırlaması (n G) | 8700 |
| Outer ring total width (2T) mm | 50,5 |
| Thermal speed rating (n u03d1r) | 5100 |
| ECLASS number | 23-05-09-10 |
| ECLASS2 number | 23-05-09-10 |
| Medias description | Tapered roller bearing set 313..-XL-DF, X-arrangement |
| XL | X-Life |
| DF | Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings |
| A50-90 | Axial Clearance In µm |
