FAG 30228-XL-DF-A250-300
Fiyatı: 33,984.80 ₺
Özellikler
| Marka | FAG |
| Ürün No | 30228-XL-DF-A250-300 FAG |
| Üretici No | 0872271504080 |
| Alternatif Kodu |
30228-DF-A250-300 |
| EAN | 4054369500738 |
| Kategori | Konik Makaralı - Tek Sıra (Çift Metrik) |
| İç (d) MM | 140 |
| Dış (D) MM | 250 |
| En (B) MM | 91,5 |
| İç (d) Inch | 5.5118 |
| Dış (D) Inch | 9.8425 |
| En (B) Inch | 3.6024 |
| Ağırlık | 18.4 kg |
| Tapered Roller Pair Internal Play | 250-300µm |
| Inner ring total width (2B) mm | 84 |
| Radial Static Load Rating C0r (N) | 1120000 |
| Radial Dynamic Load Rating Cr (N) | 840000 |
| Temel statik yük derecesi, radyal (C 0r) | "1120000.0000" |
| Hız sınırlaması (n G) | 3100 |
| Outer ring total width (2T) mm | 91,5 |
| Thermal speed rating (n u03d1r) | 1700 |
| ECLASS number | 23-05-09-10 |
| ECLASS2 number | 23-05-09-10 |
| Medias description | Tapered roller bearing set 302..-XL-DF, X-arrangement |
| XL | X-Life |
| DF | Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings |
| A250-300 | Axial Clearance In µm |
