FAG 30220-A-DF-A220-270
Fiyatı: 9,976.40 ₺
Özellikler
| Marka | FAG |
| Ürün No | 30220-A-DF-A220-270 FAG |
| Üretici No | 0841967934081 |
| EAN | 4054369005110 |
| Kategori | Konik Makaralı - Tek Sıra (Çift Metrik) |
| İç (d) MM | 100 |
| Dış (D) MM | 180 |
| En (B) MM | 74 |
| İç (d) Inch | 3.937 |
| Dış (D) Inch | 7.0866 |
| En (B) Inch | 2.9134 |
| Ağırlık | 7.82 kg |
| Tapered Roller Pair Internal Play | 220-270µm |
| Inner ring total width (2B) mm | 68 |
| Radial Static Load Rating C0r (N) | 650000 |
| Radial Dynamic Load Rating Cr (N) | 430000 |
| Temel statik yük derecesi, radyal (C 0r) | "650000.0000" |
| Hız sınırlaması (n G) | 4000 |
| Outer ring total width (2T) mm | 74 |
| Thermal speed rating (n u03d1r) | 2650 |
| ECLASS number | 23-05-09-10 |
| ECLASS2 number | 23-05-09-10 |
| Medias description | Tapered roller bearing set 302..-A-DF, X-arrangement |
| A | Internal Design Modification |
| DF | Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings |
| A220-270 | Axial Clearance In µm |
