FAG 30212-XL-DF-A100-140
Fiyatı: 2,301.20 ₺
Özellikler
| Marka | FAG |
| Ürün No | 30212-XL-DF-A100-140 FAG |
| Üretici No | 0862666164080 |
| Alternatif Kodu |
30212-DF-A100-140 |
| EAN | 4054364843663 |
| Kategori | Konik Makaralı - Tek Sıra (Çift Metrik) |
| İç (d) MM | 60 |
| Dış (D) MM | 110 |
| En (B) MM | 47,5 |
| İç (d) Inch | 2.3622 |
| Dış (D) Inch | 4.3307 |
| En (B) Inch | 1.8701 |
| Ağırlık | 1.97 kg |
| Tapered Roller Pair Internal Play | 100-140µm |
| Inner ring total width (2B) mm | 44 |
| Radial Static Load Rating C0r (N) | 246000 |
| Radial Dynamic Load Rating Cr (N) | 210000 |
| Temel statik yük derecesi, radyal (C 0r) | "246000.0000" |
| Hız sınırlaması (n G) | 7500 |
| Outer ring total width (2T) mm | 47,5 |
| Thermal speed rating (n u03d1r) | 4250 |
| ECLASS number | 23-05-09-10 |
| ECLASS2 number | 23-05-09-10 |
| Medias description | Tapered roller bearing set 302..-XL-DF, X-arrangement |
| XL | X-Life |
| DF | Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings |
| A100-140 | Axial Clearance In µm |
